13
① Remove the oil dipstick.
② Remove the oil plug for displacement to drain the
used oil.
③ Reinstall the oil plug for displacement, paying
attention to be tightened .
④ Refill 0.8 L recommended fresh engine oil.
⑤ Fa
sten all the nuts and screws.
7. Brake system
Normal free travel of the brake lever is about 10-20mm.
① The front brake (disk brake)
② T
he rear brake (drum brake)
Turn the adjusting nut to get a proper travel.
◆ FREE TRAVEL means the distance between
the positions from free status to the
beginning performance of the brake.
◆ Pay attention to the sensitivity of the brake.
a
a=10~20mm
adjusting nut
a=10~20mm
a
