3
□
□□
□ Position of parts
1. brake disc 2. disk brake assy. 3. position light 4. front shock absorber
6. head light 7. rear-view mirrors 8. helmet hook 9. side stand
11. main stand 12. starting pedal 13. rear shock absorber 14. air cleaner
16. taillight & rear turning light 17. side reflector 18. drum brake 19. rear brake lever
21. meters 22. right switches assy. 23. front brake lever 24. rear reflector
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
5. front turning light
10. seat
15. rear carrier
20. left switches assy.
25. muffler
25
