30
If you ignore these Warnings or fail to inspect or maintain your
wheelchair as directed in the manual , you may fall, tip over or lose
control of the wheelchair and seriously injure yourself or others or
damage the wheelchair.
11. TEST CONFIGURATION
Seat Width 18 in.
Seat Depth 18 in.
Seat Back Height. 20 in.
Front Seat Height 18 in.
Rear Seat Height 15.75 in.
Seat Angle 7 degrees
Seat Back Angle 90 degrees with a 8 degree bend at 8 in.
Wheelchair Weight 37 lb.
Seat Sling Tension Adjustable Slide-On
Back Upholstery Slip-on
Backrest Type Aluminum Adjustable Height 18-21 in.
Footrest Angle 70 degrees
Rear Wheels 24” spoke wheels with 0 degrees of camber
Rear Tire Soft Urethane 1.25 in
Casters 6” Polyurethane tire on a 3-spoke composite wheel
Footrest Aluminum adjustable angle
Other Options None
Mass of ATD 172 lb.
Maximum User Weight. 250 lb.
Conversion chart
Inches Metric Inches Metric Inches Metric Inches Metric
1/4” 0.6 cm 1” 2.5 cm 10” 25.4 cm 19” 48.3 cm
1/2” 1.3 cm 2” 5.1 cm 11” 27.9 cm 20” 50.8 cm
3/4” 2.0 cm 3” 7.6 cm 12” 30.5 cm 21” 53.3 cm
4” 10.2 cm 13” 33.0 cm 22” 55.9 cm
5” 12.7 cm 14” 35.6 cm 23” 58.4 cm
6” 15.2 cm 15” 38.1 cm 24” 61.0 cm
7” 17.8 cm 16” 40.6 cm 25” 63.5 cm
8” 20.3 cm 17” 43.2 cm 26” 66.0 cm
9” 22.9 cm 18” 45.7 cm
