MOTION CM-35 ELECTRONIC CURTAIN MOTOR
MOTION CM-35 ELECTRONIC CURTAIN MOTOR
Pair a remote control that is able to program blinds. See pages 6 and 7
for remote controls details. In this manual CM-12 is displayed.
Shortly press the program button on the
motor. The blind will start stepping, indicating
that program mode has been activated.
(The blind remains stepping until the program
mode is de-activated.)
Repeat steps 3.1 - 3.3 to remove a blind from
a channel.
Press the pair button on the back of the remote
control to pair the blind to the selected channel.
The blind will shortly stop stepping indicating
that the remote has been paired to the blind.
Select a desired channel for the blind using the
channel selection button on the remote control.
Channel
Selection
Pair
button
Channel
indicator
Pair a remote
Shortly press the down button to check if the
blind moves the right way: away from the
motor. If the blind moves the other way, the
rotational direction must be changed.
WARNING: risk of damage.
Stop the blind before reaching
the end positions.
Check direction of rotation
Simultaneously press the up and down button
to change the direction of rotation.
Up
Down
End limits must be programmed to use a blind properly and to prevent it from being damaged.
Proceed to step 7 if end limits are already set.
