motium MLC-1010 - Brightness and Contrast; Colour

28 MLC-1010 TUFF VIEW LCD Monitor
7.4.3. Brightness and Contrast
The options under the Brightness and Contrast menu are:
• Brightness. This is the brightness adjustment on a traditional LCD monitor. It
performs a colour shift (making each pixel darker or lighter) rather than adjusting
the actual backlight brightness.
• Contrast. This adjusts the contrast ratio of each pixel.
• Colour Control. This allows individual adjustment of the red, green and blue
colours.
• Exit.
Figure 9. Brightness and Contrast adjustment.
7.4.4. Colour
The options under the Colour menu are:
• Auto-adjust colour. This automatically adjusts the colour settings for the incoming
picture.
• sRGB display. Loads the sRGB colour profile.
• Colour temperature. Sets the monitor’s colour profile to one of the defaults
selected (4200K, 5000K, 6500K, 7500K or 9300K).
• Not used.
• Not used.
• Allows colour balance to be manually adjusted.
• Exit.
Figure 10. Colour adjustment.
