ED-002-049-07
KLICK FAST MOUNTS
Klick Fast mounts are compatible with Klick Fast docks - a standard tting on most police, public safety and security uniforms.
VB-400 Body Worn Cameras tted with Klick Fast mounts do not require additional xings, they attach straight on to
compatible uniforms.
Using the Klick Fast Mount
To attach a VB-400 with a Klick Fast Mount to your uniform, simply rotate the camera 180˚ and slide the stud down into the
Klick Fast dock attached to your uniform. Once fully docked, rotate 180˚ ensuring the camera is in an upright position as
shown.
To detached a VB-400 with a Klick Fast Mount from your uniform, simply rotate the camera 180˚ and slide the stud out of
the Klick Fast dock as shown.
Connect stud to the
dock then slide down.
Rotate 180˚ ensuring the
camera us in an upright position.
