6 AP6522 Access Point
1.4.3 Features
• 2 RJ-45 connectors, one for 10/100/1000 Ethernet and the other for the serial/console connector
• LED indicators
• Slots for wall mounting
• Clips for mounting on a suspended ceiling T-bar (internal antenna model only) with separately orderable
accessories
• Lock port for Kensington® style Security Lock
The AP6522 access point has one RJ-45 connector supporting an 10/100/1000 Ethernet port and accepts
802.3af-compliant power from an external source. The illustration below is of an integrated antenna model.
The AP6522 access point comes with dual radios supporting 802.11abgn. The access point contains runtime
firmware which enables the unit to boot after a power up. The runtime firmware on the access point and the
firmware downloaded from the connected controller can be updated via the Ethernet interface.
NOTE When operating in a Gigabit Ethernet environment, CAT-5e or CAT-6 cable
is recommended for Gigabit operation.
NOTE When connecting to an AP6522 model access point, note that the baud
rate is 115,200 as opposed to 19,200.
DC12V GE1/PoE Console
