Level 1-2 Service Manual Specifications
December 6, 2005 7
Specifications
General Function Specification
Dimensions 101mm X 47.8mm X 21.9mm
Weight Not exceed 80 grams
LCD Display B&W, Active Area: 28.58 X 19.35mm,
Pixel: 96 X 65
Band GSM900/1800 or GSM850/PCS1900
Battery 920mAh Li Ion Battery
Product type Bar type
Antenna Internal Antenna
Frequency Range (EGSM) 880-915 MHz Tx,
925-960 MHz Rx
Frequency Range (DCS) 1710 – 1785 MHz Tx,
1805-1880 MHz Rx
Frequency Range (GSM850) 824-849 MHz Tx,
869-894 MHz Rx
Frequency Range (PCS) 1850-1910MHz Tx,
1930-1990 MHz Rx
Channel Spacing 200KHz
Channels 174 WGSM, 374 DCS carrier with 8ch,
per carrier
Modulation GMSK at BT=0.3
Transmitter Phase Accuracy 5 Degrees RMS, 20 Degrees peak
Duplex spacing 45 MHz GSM, 95 MHz DCS
Frequency Stability ±0.1PPM of the downlink frequency (Rx)
Operating voltage 3.53V ~4.2V
Average Transmit Current Power Level 5: 230mA
Power Level 19: 105mA
Average Standby Current DRX 2: 6mA
DRX 9: 3mA
Temperature Range -20C to 55°C
