Disassembly/Reassembly Procedures: Radio Disassembly – Detailed 5-9
Figure 5-4. Chassis Removal from Front Housing
6. Slowly slide out the chassis assembly from the front housing Figure 5-4 until the volume and
channel selector shafts are free from the top of the housing.
Do not pull out the chassis forcefully. This will cause damage
to the speaker and microphone wires that are still connected
to the chassis assembly.
