Motorola DP1400 Series

5-10 Disassembly/Reassembly Procedures: Radio Disassembly – Detailed
Figure 5-5. Audio Jack Shroud Assembly Removal
7. Remove the audio jack shroud assembly from the accessory connector on the main board.
Audio Jack Shroud Assembly
Accesory Connector
