Motorola DP1400 Series

Disassembly/Reassembly Procedures: Radio Disassembly – Detailed 5-13
2. Place plastic flat-tip tweezer on the central part of the actuator, gently unlatch the actuator by
rotating it about 100°.
Figure 5-7. Unlatching the Actuator
Do not attempt to unlatch the actuator by applying load on the
both ends of actuator.
Flex
!
C a u t i o n
