Motorola DP1400 Series

Disassembly/Reassembly Procedures: Radio Reassembly - Detailed 5-33
5.7.6 Chassis and Front Housing Reassembly
1. Apply a thin layer of grease on both the sides and the bottom (except the top) of the main
O-ring.
2. Connect the speaker and microphone wires from the housing to the 2-pin connector on the
main board.
Figure 5-27. Chassis and Front Housing Reassembly
Microphone Wire
Speaker Wire
