Motorola DP1400 Series

Disassembly/Reassembly Procedures: Radio Exploded Mechanical View and Parts Lists 5-41
8 Battery Refer Accessory Leaflet
9 Belt Clip Refer Accessory Leaflet
10 Option Board Available from
application developer
*11 Option Board Installation Kit PMLN7228_
11.1 Screw, Option Board Part of PMLN7228_
11.2 Poron, Option Board Part of PMLN7228_
11.3 Flex, Option Board Part of PMLN7228_
NOTE
* Item 11 is not featured in the exploded view as it is a kit.
Table 5-5. Front Housing Service Kits
Item Description Motorola Part Number
Front Kit Front Cover Kit, Non-Keypad Portable PMLN6345_
Front Kit Front Cover Kit, Non-Keypad Portable, Option Board Capable PMLN7210_
Table 5-6. Back Cover Kit Part Numbers
Item Description Motorola Part Number
Back Kit Back Cover Kit, VHF, 5 W, MOTOTRBO Non-Display
Portable
WAED4508_
WAED4507_ (Analog)
Back Kit Back Cover Kit, VHF, 5 W, MOTOTRBO Non-Display
Portable, Option Board Capable
WAED4529_
WAED4530_ (Analog)
Back Kit Back Cover Kit, UHF, 4 W, MOTOTRBO Non-Display
Portable
WAEE4472_
WAEE4471_ (Analog)
Back Kit Back Cover Kit, UHF, 4 W, MOTOTRBO Non-Display
Portable, Option Board Capable
WAEE4499_
WAEE4500_ (Analog)
Table 5-4. Exploded View Part List
Item Description Part Number
