5-42 Disassembly/Reassembly Procedures: Radio Exploded Mechanical View and Parts Lists
5.8.3 Torque Chart
Table 5-7 Torque Specifications for Screws lists the various screws by part number and description,
followed by the torque values in different units of measure. Torque all screws to the recommended
value when assembling the radio.
Table 5-7. Torque Specifications for Screws
Part Number Description
Driver/
Socket
Torque
lbs-in
0304726J05 Screw, Main Board T6 TORX 3.7 to 3.9
0386434Z02 Screw, Speaker Retainer T6 TORX 2.7 to 2.9
FN000157A01 Screw, Option Board T6 TORX 1.8 to 2.0
