Motorola GP300 Series

3-22 Mechanical Views and Parts Lists
* For UHF Band 1 only.
Item
Motorola
Part
Number
Description
1 See Chapter 6 Antenna
2 3680529Z01 Volume Knob
3 3680530Z02 Frequency Knob
4 1380525Z06 Top Escutcheon
5 3385681Z02 Escutcheon Label
6 3280533Z06 Control Top Seal
7 6180527Z01 Lightpipe
8 3380660Z12 Front, Label
9 1586059A01 Dust Cover, Universal
Connector
10 1386058A01 Escutcheon, Universal
Connector
11 1380528Z03 Bezel, Side Control
12 7580532Z03 Keypad, Side Control
13 1580666Z06 Cover, Front Assembly
14 4285672Z01 Clip, Bezel
15 3586057A03 Felt, Speaker
16 1471531L01 Insulator
17 1480577C01 Boot, Microphone
18 5085738Z10 Speaker
19 5015027H01 Mini Electret,
Microphone
20 2113944F54 Capacitor, 33pF
21 8415169H01
8415169H02*
Flex, Universal
Connector
22 7586477Z01 Pad, Poron
23 2113944C81* Capacitor, 24pF
24 4286410Z01 Retainer, Speaker
25 1405307X01 Insulator kapton
26 3916290H01 Foam, Conductive
27 7580671Z01 Pad (Flexible circuit)
28 7580671Z03 Pad (Flexible Flex)
29 0304726J05 Screw, Torx T-6 (4X)
30 0104018J51 RF Board
31 1485673Z01 Insulator, Antenna
32 3980667Z04 Contact Finger (x3)
33 7580556Z02 Pad Thermal
34 3280534Z02 Battery Contact Seal
35 3286406Z01 Gasket O-Ring
36 3980698Z01 Contact, ground, VHF
37 2780518Z06
2771798M01* Chassis
38 See Chapter 6 Battery
39 HLN9714 Beltclip
