Motorola GP340 - Page 7

Technical Specifications 1-3
*Availability subject to the laws and regulations of individual countries.
Transmitter 300R1
*Frequencies - Full Bandsplit 300-350 MHz
Channel Spacing 12.5/20/25 kHz
Frequency Stability
(-25°C to +55°C, +25° Ref.)
±2.5 ppm @ 12.5kHz
±5ppm @ 25 kHz
Power 1-4W
Modulation Limiting
±2.5 @ 12.5 kHz
±4.0 @ 20 kHz
±5.0 @ 25 kHz
FM Hum & Noise -40 dB typical
Conducted/Radiated Emission
-36 dBm <1 GHz
-30 dBm >1 GHz
Adjacent Channel Power
-60 dB @ 12.5 kHz
-70 dB @ 25 kHz
Audio Response (300 - 3000 Hz) +1 to -3 dB
Audio Distortion <5% typical
Receiver 300R1
*Frequencies - Full Bandsplit 300-350 MHz
Channel Spacing 12.5/20/25 kHz
Sensitivity (12 dB SINAD) EIA
Sensitivity (20 dB SINAD) ETS
0.35 µV typical
0.50 µV typical
Intermodulation ETS -65 dB
Adjacent Channel Selectivity
-60 dB @ 12.5 kHz
-70 dB @ 25 kHz
Spurious Rejection -70 dB
Rated Audio 0.5W
Audio Distortion @ Rated Audio <3% typical
Hum & Noise
-45 dB @ 12.5 kHz
-50 dB @ 20/25 kHz
Audio Response (300 - 3000 Hz) +1 to -3 dB
Conducted Spurious Emission
-57 dBm <1 GHz
-47 dBm >1 GHz
ETS 300 086
