Motorola GP340 - Accessory Information; Attaching;Removing the Battery; Attaching;Removing the Belt Clip

8
English
BASIC USER GUIDE
ACCESSORY INFORMATION
Attaching the Battery
1. Fit the extensions at
the bottom of the
battery into the slots
at the bottom of the
radio’s body.
2. Press the top part of
the battery towards
the radio until you
hear a click.
Removing the Battery
Ensure radio is switched off.
1. Slide the battery
latches, on both sides
of the battery, down-
wards.
2. Pull the top part of the
battery away from the
radio’s body, and
remove the battery.
Attaching the Belt Clip
1. Align the grooves of
the belt clip with those
of the battery.
2. Press the belt clip
downwards until a
click is heard.
Removing the Belt Clip
1. Use a key to press
the belt clip tab
away from the
battery.
2. Slide the belt clip
upwards to remove
it.
1
2
Slots
2
1
Battery
Latches
2
1
Belt Clip Tab
