Motorola GP340 Basic User's Guide

7
English
BASIC USER GUIDE
Recycling or Disposal of Batteries
At the end of its useful life, the NiCd battery
can be recycled. However, recycling
facilities may not be available in all areas.
Motorola endorses and encourages the recycling of all
re-chargeable batteries. Contact your dealer for further
information.
Charging the Battery
If a battery is new, or its charge level is very low, you
will need to charge the battery before you can use it in
your radio.
Note: Batteries are shipped uncharged from the
factory. New batteries could prematurely
indicate full charge, charge a new battery for
14-16 hrs before initial use.
1. Place the radio with the battery attached, or the
battery alone, in the charger.
2. The charger’s LED indicates the charging
progress.
Battery chargers will charge only the Motorola
authorized batteries listed below; other batteries will
not charge.
NiCd
Charger LED Status
Red Battery is charging
Green Battery is fully charged
Flashing Red * Battery is unchargeable
Flashing Yellow Charger is getting ready to charge
Flashing Green Battery is 90% charged
*
Battery is damaged. Please contact your dealer.
Part No. Description
HNN9008
HNN9009
HNN9010
HNN9011
HNN9012
HNN9013
High-Capacity NiMH
Ultra-High-Capacity NiMH
Ultra-High-Capacity Factory Mutual NiMH
High-Capacity Factory Mutual NiCd
High-Capacity NiCd
Lithium-Ion

Motorola GP340 Specifications

Power and Battery

power supply	Rechargeable Battery 7.5v
battery life with standard high capacity NiMH battery (low power)	11 hours
battery life with standard high capacity NiMH battery (high power)	8 hours
battery life with ultra high capacity NiMH battery (low power)	14 hours
battery life with ultra high capacity NiMH battery (high power)	11 hours
battery life with NiCD battery (low power)	12 hours
battery life with NiCD battery (high power)	9 hours
battery life with Li-lon battery (low power)	11 hours
battery life with Li-lon battery (high power)	8 hours

Operating Environment

operating temperature	-20°C to +55°C
sealing	Withstands rain testing per MIL STD 810 C/D/E and IP54
shock and vibration	Protection provided via impact resistant housing exceeding MIL STD 810-C/D/E and TIA/EIA 603
dust and humidity	Protection provided via environment resistant housing exceeding MIL STD 810 C/D/E and TIA/EIA 603

Transmitter Specifications

frequencies - full bandsplit	VHF: 136-174 MHz, LB1: 29.7-42 MHz, UHF: 300-350 MHz, LB2: 35-50 MHz, UHF1: 403-470 MHz
channel spacing	12.5/20/25 kHz
frequency stability	±2.5 ppm
power	136-174: 1-5W, 300-350: 1-4W, 403-470: 1-4W
modulation limiting	±2.5 @ 12.5 kHz, ±4.0 @ 20 kHz, ±5.0 @ 25 kHz
FM hum & noise	-40dB typical
conducted/radiated emission	-36 dBm <1 GHz, -30 dBm >1GHz
adjacent channel power	-60 dB @ 12.5 kHz, -70 dB @ 20/25 kHz
audio response (300-3000Hz)	+1 to -3 dB
audio distortion	3%

Receiver Specifications

frequencies - full bandsplit	VHF: 136-174 MHz, LB1: 29.7-42 MHz, UHF: 300-350 MHz, LB2: 35-50 MHz, UHF1: 403-470 MHz
channel spacing	12.5/20/25 kHz
sensitivity (12 dB SINAD) EIA	.25µV typical
sensitivity (20 dB SINAD) EN	.50µV typical
intermodulation EIA	70 dB
adjacent channel selectivity	60 dB @ 12.5 kHz, 70 dB @ 20/25 kHz
spurious rejection	70 dB
rated audio	0.5W
audio distortion @ rated audio	3% typical
hum & noise	-40 dB @ 12.5 kHz, -50 @ 20/25 kHz
audio response (300-3000 Hz)	+1 to -3 dB
conducted spurious emission	-57 dBm <1 GHz, -47 dBm <1 GHz

Weight and Dimensions

dimensions with standard high capacity NiMH battery	137 x 57.5 x 37.5 mm
dimensions with ultra high capacity NiMH battery	137 x 57.5 x 40.0 mm
dimensions with NiCD battery	137 x 57.5 x 40.0 mm
dimensions with Li-lon battery	137 x 57.5 x 33.0 mm
weight with standard high capacity NiMH battery	420 gm
weight with ultra high capacity NiMH battery	500 gm
weight with NiCD battery	450 gm
weight with Li-lon battery	350 gm
