6-8
6880904Z07-O August 13, 1996
Parts List: HLD9440A and HLD9441A, 146-174MHz
VHF Transceiver
HLD9440A and HLD9441A, 146-174MHz VHF Transceiver Board HLD9440A and HLD9441A, 146-174MHz VHF Transceiver Board HLD9440A and HLD9441A, 146-174MHz VHF Transceiver Board HLD9440A and HLD9441A, 146-174MHz VHF Transceiver Board HLD9440A and HLD9441A, 146-174MHz VHF Transceiver Board
REFERENCE
SYMBOL
MOTOROLA
PART NO.
DESCRIPTION
CAPACITOR, Fixed: pf +/-5%;
50V: unless otherwise stated
C28, C29 2113740A48 51pF
C30, C31 2113740A79 1nF
C33 2113740A24 6.8pF
C34 2113741A45 10nF
C35 2113740A53 82pF
C36 2113740A18 4.3pF
C51 2113740A53 82pF
C53 2113740A37 22pF
C54 2113740A33 15pF
C55 2160521G37 0.1uF
C56 thru C58 2113740A36 20pF
C59, C60 2160521G37 0.1uF
C61 2113741A25 1.5nF
C62 2311049A05 0.47uF
C63 2113740A48 51pF
C64 2113740A72 510pF
C65 2113741A45 10nF
C66 2160521G37 0.1uF
C67 2311049J11 4.7uF
C68 2113741A59 39nF
C69 2311049J07 3.3uF
C70 2160521G37 0.1uF
C71 2311049J25 10uF
C73 2113740A32 13pF
C74 2113740A42 36pF
C75 2113740A17 3.9pF
C77 2113740A14 3pF
C78 0660076M01 0
C79 2113740A34 16pF
C80 NU
C81 thru C84 2160521G37 0.1uF
C85 thru C87 2113740A59 150pF
C101, C102 2311049A07 1uF
C103 2113740A53 82pF
C104 2113740A63 220pF
C105 2311049J25 10uF
C106 2113740A63 220pF
C107 2113741A59 39nF
C111 2113740A71 470pF
C112 2113740A37 22pF
C113 2113740A42 36pF
C114 2113740A48 51pF
C115 2113740A39 27pF
C116 2113740A79 1nF
C117 2113740A27 8.2pF
C118 2113740A71 470pF
C119 2113740A36 20pF
C120, C121 2113740A71 470pF
C122 2113740A35 18pF
REFERENCE
SYMBOL
MOTOROLA
PART NO.
DESCRIPTION
C151, C152 2113740A71 470pF
C153 2160521G37 0.1uF
C154 2113740A71 470pF
C156 2113740A71 470pF
C157, C158 2113741A45 10nF
C159 2113740A71 470pF
C163, C164 2113740A71 470pF
C165 2113741A45 10nF
C166 2311049A05 0.47uF
C167, C168 2113741A59 39nF
C201 NU
C202, C203 2113741A45 10nF
C204 2311049J27 10uF
C205 2113740A63 220pF
C206 2113740G46 47pF
C207, C208 2311049J11 4.7uF
C209 2113740A71 470pF
C210, C211 2311049J11 4.7uF
C212 2113741A21 1nF
C214 2311049A07 1uF
C215 2113741A39 5.6nF
C216 2160521G37 0.1uF
C217 2311049J11 4.7uF
C218 2113741A21 1nF
C219 thru C221 2113740A59 150pF
C222 2113741A21 1nF
C223 2113740A41 33pF
C224 2113740A79 1nF
C226 2113740A14 3pF
C227 2113740A03 1pF
C228 2113740A59 150pF
C229 NU
C230 2160521G37 0.1uF
C231 2113741A45 10nF
C232 NU
C233 2113740G24 6.8pF
C235 2113741A51 18nF
C236 2113740A71 470pF
C237, C238 2113740A55 100pF
C251 2113740A33 15pF
C252 2113740A30 11pF
C253 2113740A34 16pF
C254 2113740A03 1pF
C255 2113740A37 22pF
C256, C257 2113740A79 1nF
C258 NU
C259 2113740A79 1nF
C260 2113740A27 8.2pF
C261 2113740A34 16pF
C262 2113740A28 9.1pF
C263 2113740A03 1pF
REFERENCE
SYMBOL
MOTOROLA
PART NO.
DESCRIPTION
C264 2113740A32 13pF
C265 2160521G37 0.1uF
C266 2113740A79 1nF
C268, C269 2113740A79 1nF
C270 2113740A17 3.9pF
C271 2113740A19 4.7pF
C272 2113740A16 3.6pF
C273 2113740A79 1nF
C275 2113740A79 1nF
C276 2113741A45 NU
C278, C279 2311049A03 0.22uF
C280 2113740A79 1nF
C281 2113740A71 470pF
C284 2113740A10 2pF
C285 2113740A71 470pF
FILTER:
CF51 9180098D06 Ceramic, 3WR (25kHz)
CF52 9180098D05 Ceramic, 3WR (25kHz)
CLIP:
CLP1 thru CLP8 4280138R02 Butterfly
DIODE: (see note)
CR2 4880174R01 Ring Mixer
CR51 4880154K03 Dual
CR101, CR102 4880973Z02 Pin
CR201, CR202 4813833C07 Dual
CR203 4805649Q04 Varactor
CR252, CR253 4805649Q04 Varactor
CR255 4805649Q04 Varactor
CONNECTOR, Receptacle:
J1 3980515C02 Antenna Contact
J2 0180117S05 Antenna Jack
JUMPER:
JU51 NU
COIL, Inductor
L9 2462587X45 22nh
L11 2462587X51 68nH
L51 2483411T63 0.15
L52 2462587X61 470nH
L53 2462587N69 1.2uH
L54 NU
L55 2483411T75 1.5
L58 2483411T74 1.2
L101thru L103 2411087B24 0.68uH
L104 2484657R01 Ferrite Bead
L106 2411087B24 0.68uH
L107 2405486C76 7T
L108 2405318D12 7T
L109 2405486C76 7T
L111 2405835C03 5T
L112 2405486C77 7T
L201 2462587N69 1.2uH
REFERENCE
SYMBOL
MOTOROLA
PART NO.
DESCRIPTION
L203 2462587N69 1.2uH
L204 2462587X56 180nH
L251, L252 2462587N69 1.2uH
L253 2480145S05 5 1/2 turns, Ferrite Core
L254 2462587X55 150nH
L255 thru L257 2462587N69 1.2uH
L258 2480145S04 4 1/2 turns, Ferrite Core
L259 2462587N69 1.2uH
L260 2483411T62 27nH
L261 2462587X55 150nH
L262 2462587X46 27nH
L267 2462587X56 180nH
L268 2462587N69 1.2uH
TRANSISTOR:
(see note)
Q51 4813827A07 NPN, Small Signal
Q151 4880214G02 NPN
Q152 4813822A10 PNP, 60V, 10Amp.
Q153 4880214G02 NPN
Q154 4880141I03 PNP
Q155, Q156 4880214G02 NPN
Q405 4805128M16 SOT, MMBT3906 (RH)
RESISTOR, Fixed
: +/-5%; 1/8W:
unless otherwise stated
R51 0660076A18 51
R52 0660076A85 33k
R53 0660076A75 12k
R54 0660076A56 2k
R55 0660076A25 100
R57 0660076B04 130k
R58 0660076A76 13k
R59 0660076A93 68k
R60 0660076A70 7.5k
R64 0660076A67 5.6k
R66 0660076A47 820
R67 0660076A69 6.8k
R68 0660076A25 100
R69 0660076A73 10k
R101 0680106R01 0.1; 1W
R102 0660076A29 150
R103 0660076A22 75
R104 0660076A36 300
R105 0660076A07 18
R106 0660076A36 300
R107 0611077A18 4.7
R108 0660076A22 75
R151 0660076E91 56k
R152 0660076F01 100k
R153 0660076A09 22
R154 0660076F01 100k
R155 0660076E91 56k
R156 0660076A63 3.9k
MOTOROLA
PART NO.
DESCRIPTION
R157 0660076A55 1.8k
R158, R159 0660076A31 180
R160, R161 0660076A45 680
R162 0660076A27 120
R166 0660076A31 180
R167 0660076A78 16k
R168 0660076B01 100k
R169 0660076A73 10k
R170 NU
R171 0660076A90 51k
R172 0660076A81 22k
R173 NU
R174 0660076B01 100k
R175 0660076A68 6.2k
R179 0660076A38 360
R201 0660076A18 51
R202 0660076A49 1k
R203 0660076B06 160k
R204 0660076B02 110k
R205, R206 0660076A57 2.2k
R207 0660076A65 4.7k
R211 0660076A89 47k
R212 0660076A73 NU
R215 0660076A49 1k
R216 0660076A82 24k
R251 0660076A95 82k
R253 0660076A60 3k
R254 0660076A73 10k
R257 0660076A89 68k
R258 0660076A25 100
R260, R261 0660076A33 220
R263 0660076A70 7.5k
R264 0660076A01 10
R265 0660076I17 4.7
R438 0660076A61 3.3k
SHIELD:
SH100 2680521D02 Synthesizer Front
SH101 2680520D02 VCO Front
SH103 2680518D02 Synthesizer Back
SH104 2680692C03 Mixer Back
SH105 2680519D02 VCO Back
TRANSFORMER:
T1, T2 2580163M03
INTEGRATED CIRCUIT: (see
note)
U1 0180706Y82 Front End Module
U51 5180207R01 IFIC
U101 5180111R02 Power Amplifier
U151 5180932W01 Linear Op. Amp.
U152 5105226P38 DA Converter
U201 5105457W61 Synthesizer
REFERENCE
SYMBOL
MOTOROLA
PART NO.
DESCRIPTION
U251 5105414S84 VCO Buffer
CRYSTAL:
Y51A, Y51B 9180112R05 45.1MHz Filter
Y53 4880008K02 44.85MHz
Y201 4880114R02 16.8MHz Clock
NOTE: For optimum performance, order replacement diodes, transistors, and
integrated circuits by Motorola part number only. When ordering crystal units,
specify type number, frequency, and Motorola part number.
