Motorola GP68 - Parts List for PMLN4061 Display

14 6881086C09-O March, 1997
Parts List
PMLN4061A, Display Board 20/25 KHz
REFERENCE
SYMBOL
MOTOROLA
PART NO.
DESCRIPTION
RESISTOR, Fixed: ohm+-5%
.0625W unless stated
R803 0662057A09 22
R802 0662057A25 100
R801 0662057A41 470
R816 0662057A49 1k
R817 0662057A49 1k
R811 0662057A81 22k
R812 0662057A81 22k
R815 0662057A89 47k
R814 0662057B02 150k
R813 0662057B47 0
JACK:
J801 0904655J01 Connector, Header 14 position
CAPACITOR, Fixed:pF +-5%
50V unless stated
C801 2113741F41 .0047uF
LED:
DS801 4805729G90 LED
DS802 4805729G90 LED
DS803 4805729G90 LED
TRANSISTOR:
Q801 4880214G02 NPN
MODULE:
U801 5102463J14 LCD Driver, 84 Segment
LCD ASSEMBLY:
1304695J01 Bezel
3904700J01 Zebra Connector
6104703J01 Lightpipe
Parts List for
PMLN4061 Display
