Continued from front
HHoommee MMoonniittoorriinngg && CCoonnttrrooll SSyysstteemm
WWiirreelleessss CCaammeerraa
HHMMWWLL11001100
TECHNICAL SPECIFICATIONS
To g et started and customize your Home Monitoring & Control System,
visit: www.motorola.com/homemonitoring
MOTOROLA and the Stylized M logo are registered in the US Patent & Trademark Office. All other product or service names are property
of their respective owners. ©Motorola, Inc. 2004.
5628-804-1K
PRODUCT OVER PACK
MODEL DESCRIPTION UPC WEIGHT (lbs.) DIMENSIONS QUANTITY WEIGHT (lbs.) DIMENSIONS
HMWL1010 Home Monitoring & 6 12572 09722 9 1.61 5.98" x 5.98" x 5.98" 12 20.88 12.72" x 12.72" x 19.49"
Control System
Wireless Camera
Customize your system by setting up multiple events to enhance your monitoring capability…
EVENT SELECTABLE ACTION END RESULT VIEWABLE IN ARCHIVE
CHOICES ACTION DEVICES CHOICES OR REMOTE NOTIFICATION VIA EMAIL*
Motion detected None N/A Motion detected message
The same camera
Motion detected used as sensor Image capture Motion detected message with an image capture
The same camera
Motion detected used as sensor Video capture Motion detected message with a video capture
N/A = Not Applicable
NOTE: Limit of one event per camera (i.e. motion detected, image capture or video capture)
TV System NTSC (color) standard
Integrated Lens 4.3 mm, F1.8 fixed focus
Motion and Camera Lens 80 degree field of view
Focus Range 2 ft. – Infinity
Resolution 360 horizontal TV lines
Signal/Noise Ratio 48 dB
Image Sensor 1/3" CMOS
High-Speed Electronic Shutter 1/60 – 1/15,000 sec
Frequency Range 2.41 – 2.47GHz
Modulation FM
Minimum Illumination 3 lux
Current Consumption approx. 220mA
Channel Selection Electronic tuning with PLL
Output Power 10mW
RX Sensitivity -102 dBm
Typical Range Outdoors 250 feet
Typical Range Indoors 60 feet
Operating Temperature -10˚ C to +40˚ C (14˚ F to 104˚ F)
Outline Dimensions 3.25" W x 7.3" H x 4.5" D
Weight 8.5 oz
• Color video camera with integrated infrared motion detection
• 80 degree field of view for motion and camera lens
•For indoor and/or outdoor use
• Includes all mounting hardware for table top, wall or ceiling mounting
•Powered by AC wall outlet
•Features auto brightness, auto contrast, and auto white-balance picture quality adjustments settings
WIRELESS CAMERA PROGRAMMABLE EVENTS
* Real-time notifications via Base Station/Gateway and Software. Software included with Motorola’s Home Monitoring & Control System Easy Start Kit (sold separately). Broadband service such
as cable modem or DSL modem is required for notification via cell phone or Email. Either text messages or text messages with color still images are available remote notification options via
cell phones. For Email via computers, text messages including color video with sound is an additional notification option.
** System supports up to six wireless cameras.
