General information 37
The term "IC: " before the certification/registration number
only signifies that the Industry Canada technical
specifications were met.
The Ringer Equivalence Number (REN) for this terminal
equipment is 0.0. The REN is an indication of the maximum
number of devices allowed to be connected to a telephone
interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that
the sum of the RENs of all the devices does not exceed five.
This product meets the applicable Industry Canada technical
specifications.
Technical Specifications
RF frequency band 1921.536 MHz - 1928.448 MHz
Channels 5
Operating
temperature
5ºC to 45ºC
Telephone base
voltage
(AC voltage, 60Hz)
96 — 130 Vms
Telephone base
voltage
(Adapter output)
6VDC, 400 mA
Handset voltage 2.4V 500mAh Ni-MH battery pack
Charger voltage
(Adapter output)
6VAC, 300mA
