Motorola MB100 User Manual

Motorola, Inc.
101 Tournament Drive
Horsham, PA 19044
www.motorola.com/broadband
04.03.07
Rev 8
MOTOROLA, the Stylized M Logo, STARLINE, Mini-Bridger, and LIFELINE are registered in the US Patent & Trademark Office.
All other product or service names are the property of their respective owners.
©
Motorola, Inc. 2006. All rights reserved.
Specifications are subject to change without notice.
5
Model Description
Motorola
Part Number
Qty
per
MB
MB100S-2HQXH-F
5-40 / 52-1003 MHz S-split, two output, 42 dB high gain forward, QAM ADU 609.00 MHz
gain control, 14 dB internal slope, high gain return, full station 721000-001-00
MB100S-2HAXH-F
5-40 / 52-1003 MHz S-split, two output, 42 dB high gain forward, ADU 499.25 MHz gain
control, 14 dB internal slope, high gain return, full station 721000-002-00
MB100S-2HTXH-F
5-40 / 52-1003 MHz S-split, two output, 42 dB high gain forward, TDU gain control, 14 dB
internal slope, high gain return, full station 721000-003-00
MB100S-2HXXH-F
5-40 / 52-1003 MHz S-split, two output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, high gain return, full station 721000-004-00
MB100S-1HXXH-F
5-40 / 52-1003 MHz S-split, one output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, high gain return, full station 721000-005-00
MB100S-2HSXH-F
5-40 / 52-1003 MHz S-split, two output, 42 dB high gain forward, QAM ADU 711.00 MHz
gain control, 14 dB internal slope, high gain return, full station
721000-021-00
MB100S-2HXXH-E15
5-40 / 52-1003 MHz S-split, two output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, high gain return, 15A electronics module only (no housing)
721000-006-00
MB2-100SH
(“vanilla” model)
5-40 / 52-1003 MHz S-split, 2-output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, no return, standard surge arrestor (no FTEC), full station
535746-001-00
MB100K-2HQXH-F
5-42 / 54-1003 MHz K-split, two output, 42 dB high gain forward, QAM ADU 609.00 MHz
gain control, 14 dB internal slope, high gain return, full station
721000-010-00
MB100K-2HAXH-F
5-42 / 54-1003 MHz K-split, two output, 42 dB high gain forward, ADU 499.25 MHz gain
control, 14 dB internal slope, high gain return, full station
721000-011-00
MB100K-2HTXH-F
5-42 / 54-1003 MHz K-split, two output, 42 dB high gain forward, TDU gain control, 14 dB
internal slope, high gain return, full station
721000-012-00
MB100K-2HXXH-F
5-42 / 54-1003 MHz K-split, two output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, high gain return, full station
721000-013-00
MB100K-1HXXH-F
5-42 / 54-1003 MHz K-split, one output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, high gain return, full station
721000-014-00
MB100K-2HSXH-F
5-42 / 54-1003 MHz K-split, two output, 42 dB high gain forward, QAM ADU 711.00 MHz
gain control, 14 dB internal slope, high gain return, full station
721000-027-00
MB100K-2HXXH-E15
5-42 / 54-1003 MHz K-split, two output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, high gain return, 15A electronics module only (no housing)
721000-015-00
MB2-100KH
(“vanilla” model)
5-42 / 54-1003 MHz K-split, 2-output, 42 dB high gain forward, manual gain control, 14 dB
internal slope, no return, standard surge arrestor (no FTEC), full station
535746-002-00
MB100A-2HXXH-F-R
5-65 / 85-1003 MHz A-split, 2-output, high gain, manual gain control, standard 14 dB slope,
high gain return, full station, RoHS compliant – AVAILABLE Q2 2007
821000-001-00
MB100J-2HXXH-F-R
5-55 / 70-1003 MHz A-split, 2-output, high gain, manual gain control, standard 14 dB slope,
high gain return, full station, RoHS compliant – AVAILABLE Q2 2007
821000-003-00
Required Accessories
SFE-100-0
SFE-100-1 to -22
SCS-1 to SCS-10
Starline Forward 1003 MHz equalizer (0 dB) -or-
Starline Forward 1003 MHz equalizer (values 1 to 22 dB in 1 dB steps) -or-
Starline Cable Simulator (values 1 to 10 dB in 1 dB steps)
527333-001-00
527296-001 to -022
477888-001 to -010
1
SRE-*-* Starline Return Equalizer, 5-40 MHz (S-split), 5-42 (K-split), 5-55 (J-split), 5-65 (A-split),
values 0-12 dB in 1 dB steps for S-split (2 dB steps for all other frequency splits)
478176-XXX-00 1
JXP-*B Plug-in attenuator/pad (values 0 to 26 dB, in 1 dB steps) 474011-XXX-00
≤ 9
(dual
output)
Optional Accessories
SP100
DC100/8
DC100/10
DC100/12
Splitter (1 GHz) to activate third output -or-
Directional Coupler (1 GHz) to activate third output (8 dB)
Directional Coupler (1 GHz) to activate third output (10 dB)
Directional Coupler (1 GHz) to activate third output (12 dB)
529863-001-00
529864-001-00
529864-002-00
529864-003-00
1
MB100 Ordering Information
