Motorola MOTOTRBO DP4401 EX - Receiving and Making Calls; Selecting a Zone; Selecting a Channel, Subscriber ID, or Group ID

Identifying Radio Controls
English
6
Identifying Radio Controls
Take a moment to review the following:
Radio Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
Programmable Buttons . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Push-To-Talk (PTT) Button . . . . . . . . . . . . . . . . . . . . . . page 8
Switching Between Conventional Analog and
Digital Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 9
IP Site Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 10
Capacity Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 10
Linked Capacity Plus. . . . . . . . . . . . . . . . . . . . . . . . . . page 11
Radio Controls
Channel Selector Knob
On/Off/Volume Control Knob
LED Indicator
Side Button 1*
Push-to-Talk (PTT) Button
Side Button 2*
Side Button 3*
Microphone
1
2
3
4
5
6
7
8
Speaker
Universal Connector for Accessories
Emergency Button*
Antenna
* These buttons are programmable.
12
8
6
5
2
1
11
4
10
3
9
7
9
10
11
12
