Motorola P100 Series User Manual

30
FRONT PANEL
PROGRAMMING MODE
English
Main
Menu
1st Level
Sub-Menu
2nd Level
Sub-Menu
Settings Remarks
CHANNEL SQUELCH
(Squelch Level)
CH-001...
CH-099
NORMAL
TIGHT
NORMAL squelch level allows the radio to receive weak signals. TIGHT
squelch level allows the radio to receive strong signals and eliminates
unwanted noise.
TIME OUT (Time
Out Timer)
–
OFF
010
020
...
590
600
This determines the maximum duration (in seconds) that the radio can
transmit continuously.
POWER (Power
Level)
CH-001...
CH-099
HIGH
LOW
Power level – HIGH or LOW.
PRIME CH (Prime
Channel)
–
OFF
001
...
099
The channel that you wish to spend most of your time monitoring. The
radio always switches back to the Prime Channel if it is idle for more than
the preprogrammed hang-time in other channels.
SCAN LIST 1 (*)
(Scan List 1)
01-XXX
02-XXX
…
15-XXX
16-XXX
_ _ _
001
…
099
Allows you to set members of Scan List 1. “XXX” denotes the selected
scan list member. “_ _ _” shows that no scan list member is selected.
User can use the button or the button to scroll the
valid channel list and press PTT to set the selection. Or user can directly
enter valid channel number via keypad and press PTT to set the
selection. (*)
LIST 2 (*)
(Scan List 2)
01-XXX
02-XXX
…
15-XXX
16-XXX
_ _ _
001
…
099
Allows you to set members of Scan List 2. “XXX” denotes the selected
scan list member. “_ _ _” shows that no scan list member is selected.
User can also use the button or the button to scroll
the valid channel list and press PTT to set the selection. Or user can
directly enter valid channel number via keypad and press PTT to set the
selection. (*)
(*) Only supported in Full Keypad Models.
