Motorola PRO5150 User Manual

1
English
CONTENTS
CONTENTS
Computer Software Copyrights. . . . . . . . . . 2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Safety and RF Exposure
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . 3
Battery Information . . . . . . . . . . . . . . . . . . . 3
Charging Batteries . . . . . . . . . . . . . . . . . 3
Radio Overview . . . . . . . . . . . . . . . . . . . . . 5
Parts of the Radio . . . . . . . . . . . . . . . . . . . . 5
PRO5150™ Model. . . . . . . . . . . . . . . . . 5
On/Off/Volume Knob . . . . . . . . . . . . . . . 6
Channel Selector Knob . . . . . . . . . . . . . 6
LED Indicator . . . . . . . . . . . . . . . . . . . . . 6
Programmable Buttons . . . . . . . . . . . . . 6
Push-to-Talk (PTT) Button. . . . . . . . . . . 8
Microphone . . . . . . . . . . . . . . . . . . . . . . 8
Keypad Keys (for radios with
keypads) . . . . . . . . . . . . . . . . . . . . . . . . 8
Audio Indicators for Programmable
Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Getting Started . . . . . . . . . . . . . . . . . . . . 11
Battery Information . . . . . . . . . . . . . . . . . . 11
Charging the Battery . . . . . . . . . . . . . . 11
Battery Charge Status . . . . . . . . . . . . . 12
Attaching the Battery . . . . . . . . . . . . . . 13
Removing the Battery . . . . . . . . . . . . . 13
Accessory Information . . . . . . . . . . . . . . . 14
Attaching the Antenna . . . . . . . . . . . . . 14
Removing the Antenna . . . . . . . . . . . . 14
Attaching the Belt Clip . . . . . . . . . . . . . 15
Removing the Belt Clip . . . . . . . . . . . . 15
Attaching the Side Connector Cover . . 16
Turning The Radio On or Off . . . . . . . . . . 16
Adjusting the Volume . . . . . . . . . . . . . . . . 17
Selecting a Radio Channel. . . . . . . . . . . . 17
Sending a Call . . . . . . . . . . . . . . . . . . . . . 17
Receiving a Call . . . . . . . . . . . . . . . . . . . . 17
Radio Calls . . . . . . . . . . . . . . . . . . . . . . . 19
Receiving a Selective Call . . . . . . . . . . . . 19
Receiving a Call Alert™ Page . . . . . . . . . 19
Sounding an Emergency Siren. . . . . . . . . 19
Repeater or Talkaround Mode. . . . . . . . . 20
Setting Tight or Normal Squelch. . . . . . . . 20
Setting the Power Level . . . . . . . . . . . . . . 20
Scan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Starting or Stopping Scan. . . . . . . . . . . . . 21
Scanning a Priority Channel . . . . . . . . 21
Talkback . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Deleting a Nuisance Channel. . . . . . . . . . 22

Motorola PRO5150 Specifications

General

Channel Capacity	16 channels
Dimensions	137 mm x 57.5 mm x 37.5 mm
Operating Temperature	-30°C to +60°C
Emergency Button	Yes
IP Rating	IP54
Frequency Range	136-174 MHz, 403-470 MHz
Power Output	VHF: 5W, UHF: 4W
Weight	420 g (with battery)
Signaling	MDC1200
Battery Life	Up to 11 hours (with high capacity battery)
