Motorola radius P110

May, 1997 6880904Z68-O 13
P110 16-Channel Portable Radios Getting Started
Method A:
1. Hold radio horizontally with
speaker side facing down
(Figure 3).
2. Pull battery latches, at the
same time, towards the front of
the radio housing using your
thumb and index finger (arrows
1).
3. Use your thumb to slide the bat-
tery towards the bottom of the
radio about 1/2 inch (arrow 2).
4. Pull the battery away from the guide rails and remove
from housing.
Method B:
1. Hold radio with the speaker
side in the palm of your right
hand (Figure 4).
2. Push battery latches, at the
same time, towards the front of
the radio housing using your
thumb and index finger (arrow 1).
3. Use your thumb of your right
hand to slide the battery
towards the bottom of the radio
about 1/2 inch (arrow 2).
4. Pull the battery away from the guide rails and remove
from housing.
Figure 3. Method A
1
1
2
Back of
Radio
Figure 4. Method B
2
1
Speaker
