RADIO OVERVIEW
English
27
Charging a High Capacity or Ultra
High Capacity Battery
To convert the charger from the default setup to
accommodate the High capacity or Ultra High
capacity battery:
1. Squeeze both tabs on each side of the
removable bracket in the drop-in charger tray
and lift the bracket from the charger tray.
2. Rotate the removable bracket 180 degrees and
replace it by fitting it in the charger slot until it
snaps. The label on the removable bracket
should show ‘High & Ultra Capacity Battery’
facing front of the charger.
3. Repeat same procedure to return to the
charging a Standard Battery position. Label on
the removable bracket should show ‘Standard
Battery’ facing front.
Note: Make sure the bracket is assembled
correctly for both standalone battery and
battery (with radio)
Removable
Piece
Removable
Piece
Turn around
horizontal
180 degree
To Next Page
