Motorola RFS7000 Series Installation Guide

LED Codes
5
3.1.2 Switch Status (Primary System)
3.1.3 Switch Status (Redundant System)
3.1.4 Fan LED
System Status 1 LED System Status 2 LED Event
Off Off Power off
Green Solid Off No Redundancy Feature Enabled
Green Solid Green Solid
Redundancy Feature Enabled
Actively Adopting Access Ports
Green Solid Amber Blinking
No License to adopt Access Ports or No Country
Code configured on the switch.
System Status 1 LED System Status 2 LED Event
Off Off Power off
Green Solid Off No Redundancy Feature Enabled
Green Blinking Green Solid
Redundant System failed over and adopting
ports
Green Blinking
Alternating Green Blinking
& Amber Blinking
Redundant System not failed over.
Green Solid Amber Blinking
No License to adopt Access Ports or No Country
Code configured on the switch.
Fan LED Event
Off System Off / POST Start
Green Blinking POST in Process
Green Solid All System Fans Normal Operation
Amber Solid
Redundant Cooling Failure
System Operational
Amber Blinking
System Cooling Failure
System will be held in reset until the issue is
resolved
