FREQUENCY AND CODE
CHARTS
RMM2050 – VHF-MURS DEFAULT FREQUENCIES CHART
Especial Features Requirements
• Non repeater capable.
• Non-bandwidth selectable (the FCC defines the specific bandwidth requirement for each of the MURS
frequencies).
• No power select feature.
• No direct frequency input (does not support programming of part 90 frequencies).
• No standard frequency pull down MENU (should only have the 5 MURS frequencies).
Cloning should follow standard BL Solomons platform rules; no cloning between radios of different
channel distribution (ie. CP110 and RDX) or models from different regions.
RM VHF-MURS 5CH Radios Default Frequencies – RMM2050
Channel Frequency #
Frequency
(MHz)
Code # Code Bandwidth
1 1 154.5700 1 67.0 Hz 20.0 kHz
2 2 154.6000 1 67.0 Hz 20.0 kHz
3 3 151.8200 1 67.0 Hz 11.25 kHz
4 4 151.8800 1 67.0 Hz 11.25 kHz
5 5 151.9400 1 67.0 Hz 11.25 kHz
