Motorola TETRA MTP810 EX - Battery Capacity Information

23
English
Battery Capacity Information
Attaching the Antenna
Insert the bottom of the antenna into the screw-in base on the top of
the MTP850 Ex/MTP810 Ex. Turn clockwise until snug. Do not
force.
Information Description
Green icon Full (50% - 100% capacity)
Yellow icon Middle (20% - 50% capacity)
Red icon Low (10% - 20% capacity)
Empty icon Very low (5% - 10% capacity)
Low battery message Less than 5% capacity
Turn the MTP850 Ex/MTP810 Ex Off before installing or removing
the antenna.
Battery Capacity
Empty Full
