Motorola XT1527 Service & Repair Manual

ASSY,HSG,REAR,STYX,LICORICE
ASSY,HSG,REAR,STYX,WHITE
1
TRANSDUCER,SDRP0612HJ05-02-G AAC 6X12X2MM RCVR
2
DIE CUT,ADHES,EARPC SPK,STYX
3
1. Remove the Earpiece Speaker Adhesive from
the carrier.
2. Place the Earpiece Speaker Adhesive on the
Earpiece Speaker as shown.
3. Press down on the Earpiece Speaker Adhesive
to secure it to the Earpiece Speaker.
