7
1-4 Attach the Rubber Pad
Attach one of the Feet (#L) to the Leg (#G), using Bolts (#b) and tighten until secure using
the 5mm Hex Wrench (#f).
Turn the desk over so that it is standing on the feet. Attach the Rubber Pads (#h)
to the top of the Leg Sections and Frame Joint (#N, O) in the locations shown here.
All 23 pads will be used.
O
L
N
f
b
h
To Next Page
