CAUTION:To select the correct bolts(M-A or M-C)
for your monitor, you can try to screw it on your
monitor by hand. The one can screw inside is the
correct bolt for your monitor.
STEP 3: Attach Monitor
A
A
M-A
M-C
M-E
K
04
M-B
M-D
M-E
M-F
K
OPTION A: Flat Back Monitor
For flat back monitor, secure VESA plate (A) to monitor
using screws (M-A or M-C) and washers (M-E).
OPTION B: Curved Back Monitor
For monitor with curved or recessed back, align spacers (M-F)
with mounting holes in monitor, and secure VESA plate (A) to
monitor using screws (M-B or M-D) and washers (M-E).
