STEP 4: Hang Monitor
05
Slide the monitor onto the head of swivel arm (B). Install the plastic cover (H) and security bolt (I).
Tighten the bolt with the supplied 4mm Allen key (J). Make sure the security bolt (I) is installed
before you rotate the monitor.
I
J
H
B
B
It's suggested to hang the two monitors at the
same time to prevent the danger of tipping.
