Confi guration 2 Instructions (continued)
For Urban (Jungle) models
5. Fit second snaplock to position B.
6. Fit small screw and cover button to hole C.
For Terrain Models
5. Fit second snap lock to position C.
6. Fit small screw and cover button to hole B.
Fitting the Sliding Plate to the Carrycot
• Position sliding plate on opposite side of Carrycot to snap locks.
• Sliding plate screws are located at Holes A and C in side of Carrycot. Hole B is not
required.
• There are 4 screw holes in sliding plate. Use diagram below to locate which two
holes are required for your stroller model.
Urban
• Align Hole 1 of sliding plate with Hole A of Carrycot.
Align Hole 3 of sliding plate with Hole C of Carrycot.
• Place screws into Holes 1 and 3. Using Allen key,
tighten in a clockwise direction.
1
4
2
3
A
B
C
URBAN
TERRAIN
C
B
A
3
URBAN
1
