10
Fit the dashboard cover (4) clicking the seven fasteners into
place.
Fit the steering wheel (5) onto the hub (1) with the spokes
directed towards the seat.
Fit the spacer (6) and fasten the steering wheel in place using
the screws supplied (7), in the indicated order.
Fit the steering
wheel cover (8)
clicking the three
fasteners into place.
3.3 FITTING
THE SEAT
Mount the seat (1)
on the plate (2) using
the screws (3).
3.4 ASSEMBLY AND CONNECTING THE BATTERY
The battery (1) is housed under the seat and secured by a
spring (2).
First connect the red wire (3) to the positive pole (+) and then
the black wire (4) to the negative pole (–), using the screws
supplied as shown.
Apply silicone grease to the terminals and check that the pro-
tective cap for the red wire (8) is in place.
Always fully charge the battery accord-
ing to the instructions in the battery’s manual (
☛
6.2.5).
To prevent the safety device in the elec-
tronic circuit board from cutting in, never start the engine
until the battery is fully charged!
Do not use the machine without the
guard (2) or with the battery incorrectly fixed in its
housing.
WARNING!
IMPORTANT
IMPORTANT
EN
