Mountfield HP42H User Manual

9
BEFORE EACH USE
• Always ensure that the mower is in a safe working condition. Inspect the cutter blade for damage; check safety
devices and guards; check that all nuts, bolts and screws are secure.
• Check the oil level as follows:
a) Remove the oil ller cap and wipe the dipstick clean (Figure 9).
b) Ret the dipstick into the ller neck without screwing it down.
Remove the dipstick and check the oil level; oil should be at the FULL
mark. The oil tank capacity is about 0,55 litre or 20 uid oz.
c) If the oil level is low add Mounteld oil part number MX855 or a
SAE 10W-30 oil, to the upper limit on the dipstick. Do not overll; the
oil level should not be above the FULL mark.
• Fill the fuel tank with unleaded petrol. Do not overll, there is no need
to ll tank to the top. The fuel tank need only contain enough fuel to
complete the days mowing. If you run out of fuel, relling must only be
carried out once the engine has cooled. Fuel stored within the machine
for 28 days or more can go stale and should be drained before further use.
MAINTENANCE
Stop the engine and disconnect the spark plug lead before working on the machine.
DO NOT TIP THE MOWER ONTO ITS SIDE AS THIS WILL FLOOD THE AIR FILTER WITH OIL.
To access the underside of the machine, lift the front wheels by lowering the handle until it rests on the ground.
CUTTER BLADE
Examine the cutter blade regularly for wear or damage.
• A slightly worn blade can be re-sharpened by your local dealer
• If the blade is damaged it should be replaced. Replacement blade kits are available from your Mounteld stockist.
If in doubt refer to your dealer, or telephone 0800 121 6585.
Blade must always be marked with part number 81004341/3 (HP42H-SP42H)
81004346/3 -81004460/0 (SP46H)
81004459/0 (SP53H)
CLUTCH CABLE ADJUSTMENT
• Make sure that the clutch lever is fully released
• Adjust the tension of the belt with the nut (1) to get the right measurement (6 mm)
(Figure 10)
• Engage the clutch lever and check that the rear wheels lock when the mower is pulled
backwards
• Start the mower and ensure it does not drive when the lever is disengaged
ENGINE
An engine Manufacturer’s Owner’s Manual is supplied with your mower.
Please read this, it provides detailed information on engine operation, maintenance and
care. Repair work other than routine maintenance, should be carried out by an
authorised dealer.
STORAGE
A little time spent on your mower after use will ensure many years of reliable mowing.
To access the underside of the cutter deck, ensure that the spark plug lead is disconnected. Then lift the front wheels
by lowering the handle until it rests on the ground. Do not tip the mower onto its side, as this will ood the air lter
with oil. Failure to maintain and care for your engine may invalidate the machine guarantee. Please see the guarantee
statement for full terms and conditions.
AFTER EACH USE
• Remove any grass pulp from the underside of the cutter deck using a non-metallic instrument such as a piece of
wood. Take care not to damage the paintwork.
• Examine the cutter blade for any damage. A damaged blade may upset the balance of your mower and cause
excessive vibration. If in doubt refer to your dealer.
• Inspect the grass collector and clean it if necessary. If the mesh becomes clogged airow will be reduced and impair
grass collection.
• The handle can be folded down to reduce the amount of storage space required. Take care not to trap any of the
operating cables when folding or unfolding the handle.
• Store the mower in a clean, dry area well away from any naked ames, sparks or heat source
Oil Filler Cap
Dipstick
Upper Limit
Lower Limit
Figure 9
Figure 10
1
1
6 mm
