4
ENGLISH
GB
GRASS COLLECTOR
• Fit the fabric bag over the steel frame and then
snap the bag onto the plastic lid.
• Lift the deflector.
• Locate the corners of the collector frame in the
bottom of the mower backplate and pivot the
collector so that it rests on the back of the ma-
chine.
Never use the mower without the grass
collector fitted on the machine.
USING THE LAWNMOWER
CONNECTION
Only use the machine with the cable supplied with
your mower.
If the cable is damaged, it must be replaced by an
authorised serviced dealer. Use only original spare
part 1114-0049-01.
START / STOP
Start the lawnmower on a flat, firm surface. Do not
start in long grass. Press the handle down so that
the front wheels are raised slightly from the ground
to reduce grass resistance
Starting the motor:
1. Press the button.
2. Squeeze the handle towards the handlebar.
Stopping the motor: Release the handle.
1
2
3
4
1
2
