EN
IMPORTANT - READ CAREFULLY BEFORE USING THE MACHINE. Keep for future reference
below. You are also asked to carefully read the safety regulations in the
Replace damaged or unreadable labels (see pictures on page 2).
41. Warning: Read the instruction manual before using the machine.
42. Risk of thrown objects. Keep all persons away from the work area
whilst mowing.
43. Danger of cutting yourself. Moving blades. Do not put hands or
feet near or under the opening of the blade housing. Disconnect
the spark plug cap and read the instructions before carrying out any
maintenance or repairs.
44. Only for electric lawnmowers
45. Only for electric lawnmowers
46. Danger of cutting yourself. Moving blades. Do not put hands or feet
near or under the opening of the blade housing.
Technical specications (see page 2)
[61] Nominal power
[62] Max. engine operation speed
[63] Machine weight
[64] Cutting width
[65] Sound pressure level, measured
[66] Measurement uncertainty
[67] Sound power level, measured
[68] Sound power level, guaranteed
[69] Vibration level
[70] Blade code
SAFETY REGULATIONS
A) TRAINING
1) Read the instructions carefully. Become familiar with the controls and
the proper use of the lawnmower. Learn how to stop the engine quickly.
2) Never allow children or persons unfamiliar with these instructions to
use the lawnmower. Local regulations can restrict the minimum age of
the operator.
– when people, especially children or pets are nearby;
– if the operator is tired or unwell, or has taken medicine, drugs, alcohol
or any substances that may impair their ability to react and be attentive.
unexpected events occurring to other people or their property.
B) PRELIMINARY OPERATIONS
1) Whilst mowing, always wear sturdy slip-resistant footwear and long
trousers. Do not operate the lawnmower when barefoot or wearing open
sandals.
2) Thoroughly inspect the entire work area and remove anything that could
be thrown by the machine or damage the cutting unit or engine (stones,
branches, iron wire, bones, etc.).
– store the fuel in suitable containers;
– add fuel using a funnel, only outdoors; never smoke whilst doing this and
whenever fuel is handled;
– add petrol before starting the engine; never add petrol or remove the
petrol tank cap whilst the engine is running or when it is hot;
– if you have spilt some fuel, do not attempt to start the engine but move the
lawnmower away from the area of spillage to avoid creating any source
of ignition until the fuel has evaporated and fuel vapours have dissipated.
– always put the tank and fuel container caps back on and tighten well;
5) Before use, always inspect the machine and in particular:
- the safety lever must move freely, it must not need forcing and should
return automatically and rapidly back to the neutral position determining
the cutting blade stopping;
- to see that the blade, screws and cutting unit are not worn or damaged.
Replace damaged or worn blades and screws to preserve balance. Re-
place damaged or unreadable labels.
GETTING TO KNOW THE MACHINE
DESCRIPTION OF THE MACHINE AND ITS RANGE OF USE
This machine is a garden equipment, namely a pedestrian controlled lawn-
mower.
The machine is essentially composed of a engine which drives a blade
enclosed in a casing, equipped with wheels and a handle. The operator
is able to operate the machine and use the main controls, always staying
behind the handle at a safe distance from the rotating blade. If the operator
leaves the machine, the engine and blade will stop within a few seconds.
Intended use
This machine was designed and manufactured for cutting (and collecting)
grass in gardens and grassy areas, in areas in proportion to its cutting
capacity, done by a pedestrian operator. The presence of accessories or
grass on the ground.
Improper use
Any other usage may be hazardous and harm persons and/or damage
things. Examples of improper use may include, but are not limited to:
– transporting persons, children or animals on the machine;
– letting oneself be transported by the machine;
– using the machine to tow or push loads;
– using the machine for leaf or debris collection;
– using the machine to trim hedges, or for cutting vegetation other than
grass;
– use of the machine by more than one person;
– using the blades on surfaces other than grass.
IDENTIFICATION LABEL AND MACHINE COMPONENTS
(see pictures on page 2)
1. Acoustic power level
2. Conformity marking
3. Year of manufacture
4. Type of lawnmower
5. Serial number
6. Name and address of Manufacturer
7. Article Code
8. Engine power and speed
9. Mass in kilograms
11. Chassis
12. Engine
13. Blade (Blade)
14. Stone-guard
15. Grass-catcher
16. Handle
17. Throttle trigger
18. Engine brake lever
19. Drive engagement lever
-
An example of the declaration of conformity can be found on page 12 of
this manual.
DESCRIPTION OF SYMBOLS ON CONTROLS
(where applicable) (see pictures on page 2)
21. Slow 22. Fast 23. Choke
24. Engine Stop 25. Drive on
26. Idle 27. Engine ignition
36. Grass-catcher contents indicator: lifted (a) = empty / lowered (b) = full
SAFETY REQUIREMENTS - Your lawnmower must be used carefully.
Symbols have therefore been placed on various parts of the machine to
remind you of the main precautions to be taken. Their meaning is explained
