1.4 On models with an electric starter, connect the battery cable to the
lawnmower’s general cable connection.
2. DESCRIPTION OF CONTROLS
2.1 The blade brake is controlled by the lever (1), which should be
held against the handle when starting and using the lawnmower.
The engine stops when the lever is released.
2.2 In the power-driven models, pull the lever (1) towards the
handle for forward movement. The lawnmower stops moving
forward when the lever is released.
2.3 The cutting height is adjusted using the levers (1).
On some models, this adjustment is made by fitting the
wheels into the required holes (2). The four wheels must
be at the same height.
MAKE THIS ADJUSTMENT ONLY WHEN THE BLADE HAS
STOPPED MOVING.
1
2.2
1
1
2.3
1
2.1
1.4
