STEP 15 - ASSEMBLE THE UPHOLSTERY
Int. Hex flap head screw
M8X25
NAME QTY
10x
25
Seat upholstery
NAME
upholstery
NAME
R
S
30
Allen 6 mm
Tools
ASSEMBLE
25
25
R
S
