Movement IDEA - Page 67

5
STEP 12
24
34
Screw Hex. Socket Cyl. Head
M10X25
NAME Qty
8x
2
Flat washer - M10
NAME Qty
8x
35
Eje
NAME
Qty
4x
37
Spring
NAME Qty
1x
3
Screw hexagon domed head
M8X25
NAME Qty
4x
Q1
Seat
NAME
Qty
1x
Q3
Axis plate
NAME
Q2
Axis plate with adjustment
NAME Qty
1x
R
Seat upholstered
NAME
TOOLS
Allen n° 5
Allen n° 8
100%
Qty
3x
ASSEMBLY
Q2
34
34
2
2
Q1
35
35
Q3
Q3
2
34
22
3
2
1
R
Q1
3
