29
Screw hexagon domed head
M6X16
NAME Qty
3x
13
Hex nut insert
M6
NAME Qty
2x
30
Lock plate
NAME
Qty
2x
32
Steel cable tensioner
NAME Qty
1x
31
Low profile lock nut
M8
NAME Qty
1x
5
STEP 11
O
Smaller steel cable
NAME
Qty
1x
P
Load multiplier
NAME
1
2
4
5
6
7
29
13
O
O
P
O
30
30
O
31
32
O
I
Load
multiplier
Counter nut
Maximum distance 3,0 cm
Maximum distance 2,5 cm
Recess
8
23
TOOLS
Allen n° 4
100%
Fixed Wrench
13 mm
33
Left hand hex nut - M8
NAME Qty
1x
33
ASSEMBLY
DANGER!
When mounting the steel cable tensioner
(32) the recess should face downwards.
As shown in figure 4.
Respect measures according to figure 4
3
O
P
ATTENTION!
For the passage of the cable (O) in
the load multiplier (P) must be
remove the locking pins, pass the
cable and replace the locking pins
