ARMS
Allows the user to do the exercise. The arms can be moved independently. The arms also have
counter weights, which is to compensate the weight of the arm or compensate to balance the
weight of the arm.
SEAT
Allows the user to adjust the height they want to perform the exercise.
OPERATIONAL INSTRUCTION
Load multipler
Lock nut
Maximum distance 3,0 cm
Maximum distance 2,5 cm
Recess
Maximum distance 2,5 cm
Recess
Lock Nut
Lock nut
Maximum distance 2,5 cm
Equipment with load multiplier Equipment without load multipler
DANGER!
It is extremely important to maintain the adjustment
measurements of the cables in order to avoid them coming
loose and causing serious or fatal injury to the user.
UPPER SHROUD / TRINKET BOX
The trinket box allows the user to support his squeeze as well as his cell phone and other objects.
SERIAL NUMBER
The serial number contains the information relating to the equipment class and manufacturer
data. Do no remove the series number sticker as it helps to provide information far an authorized
pint or the manufacturer. Ifthe sticker comes loose, contact the manufacturer immediately.
