30
OPERATING INSTRUCTIONS
ELECTRONIC MODULE
AIR BIKE
CALORIES
•
Press the TARGET CALORIES key (KEY 13) and the CALORIES display (DISPLAY 5) will light up, along
with a 1s audible alert.
•
Press UP / DOWN (KEY 10 or 11) to adjust the value (Figure 43) then press ENTER (KEY 19) to con!rm.
•
The preset CALORIES value counts down, TIME (DISPLAY 3), DISTANCE (DISPLAY 4), WATTS (DISPLAY 6),
SPEED (DISPLAY 2) and RPM (DISPLAY 1) start counting. (Figure 44)
•
No input signal for 30s, console will emit 1 short beep and enter standby mode.
•
Press the START (KEY 8) once to enter the PAUSE mode, an audible alert will sound for 0.5s every 30s.
All values are shown on the display and will #ash every 4s. If training is stopped for 5 minutes, the audible
alert will sound for 2s and go into standby mode. Press START (KEY 8) to resume training.
•
Press the STOP key (KEY 9) to end the training, the TIME display (DISPLAY 3) will show the total training
time; DISTANCE (DISPLAY 4) will display the total exercise distance; CALORIES (DISPLAY 5) will display the total
consumption during training; WATTS (DISPLAY 6), SPEED (DISPLAY 2) and RPM (DISPLAY 1) will change to
display AVG. & MAX. The HEART RATE display (DISPLAY 7) will change to display 65%, 85% MAX (Figure 21
~ 23) every 5s.
•
Upon input of the heart rate signal, the HEART RATE display (DISPLAY 7) will show the user's rate. If
there is no signal, nothing will be displayed. (Figure 19~20).
•
Press the TARGET TIME key to run the program.
FIGURE 41 FIGURE 42
FIGURE 43 FIGURE 44
