de altura

do assento

Assento

Regulador

Chave

(Ferramenta

para

montagem)

Secure the Handlebar Height Adjuster and secure

it using the knob with the washer, as shown in the

figure.

Insert the Handlebar Height Adjuster on the front of

the frame.

limiting the

handlebars

handlebar

Frame

screws

seat posi-

tion limiter

Handlebar

regulator

Loosen and remove the limiter of the position adjuster so

you can insert the seat. Replace the Limiter to prevent

the seat from coming loose from the assembly.

Please make sure the seat is firmly secured, tightening

the bolts and thus preventing the seat from turning on its

axis.

After mounting the horizontal set slider/Seat adjuster

assembly, attach the seat to the Horizontal slider and

tighten the bolt of the seat.

STEP 6

STEP 5

STEP 4

Frame

Seat height

adjuster

(Tool for

assembly)

Assembly

Assembly 4-2
