Mowrator S1 - Battery Specifications

37
services, please contact an authorized service provider and provide the product's model
and serial number located on the front label sticker of the battery.
Product Specifications
Parameter
Content
Name
Mowrator SteadyForce
56V 12Ah Battery
Mowrator SteadyForce
56V 18Ah Battery
Battery Model
ZMBPL5112G1
ZMBPL5118G1
Weight
16 lb
21 lb
Size
14.1 x 9.9 x 4.2 in
Operating Temperature
32℉~104℉（0°C~40°C）
Charging Temperature
32℉~113℉（0°C~45°C）
Rated Voltage
51.2V
Output (Voltage, Power)
44.8V~ 58.4V⎓
Capacity
12Ah
18Ah
Energy
614.4Wh
921.6Wh
Limited charge voltage
58.4 V
Maximum continuous charging
current
12 A
18 A
Maximum continuous discharge
current
36 A
54 A
Charging time length
70min
90min
With Mowrator 600W Supercharger，
Model 600CG4810L
Battery life
1.5h
2.25h
With Mowrator S1 series
Single battery mowing area
3000 ㎡ (0.75 ac)
4500 ㎡ (1.125 ac)
With Mowrator S1 series
Battery type
Lithium iron phosphate
Number of charge cycles
1500
