MGate MB3000 Modbus Gateway User Manual
Package Checklist
All models in the MGate MB3000 line are shipped with the following items:
Standard Accessories
• 1 MGate MB3000 Modbus gateway
• Quick installation guide (printed)
• Power adapter (MB3180, MB3280, and MB3480 only)
• Warranty card
Optional Accessories
• DK-35A: DIN-rail mounting kit (35 mm)
• Mini DB9F-to-TB Adaptor: DB9 female to terminal block adapter
• DR-4524: 45W/2A DIN-rail 24 VDC power supply with universal 85 to 264 VAC input
• DR-75-24: 75W/3.2A DIN-rail 24 VDC power supply with universal 85 to 264 VAC input
• DR-120-24: 120W/5A DIN-rail 24 VDC power supply with 88 to 132 VAC/176 to 264 VAC input by
switch
NOTE
Notify your sales representative if any of the above items is missing or damaged.
Product Features
• Integration of Modbus TCP and Modbus RTU/ASCII networks
• Auto device routing (patented)
• Up to 31 Modbus RTU/ASCII slaves per serial port
• Allow access to up to 16 (MB3180/MB3280/MB3480) or 32 (MB3170/MB3270) TCP master/client
devices, connect up to 32 TCP slave/server devices
• Configuration over Ethernet with easy-to-use Windows utility
• 10/100M Fast Ethernet with automatic IP setting (DHCP)
• Software-selectable RS-232/485/422 communication
• High-speed serial interface supporting 921.6 Kbps
• Serial port routing by IP address, TCP port, or ID mapping
• Extend transmission distance up to 4 km / 20 km through multimode/single-mode fiber models.
• ProCOM: Virtual Serial Port for flexible Modbus to Modbus TCP communication
(for MB3170/MB3170I/MB3270/MB3270I)
• Supports MXview utility
• Supports SNMP v1, v2c, and v3.
