This is a list of the flash codes which can be read and the fault codes to which they correspond.
One flash code in ECU S6 corresponds to several different fault codes.
Flash codes tables
Flashing code list for the EM S control unit
Code Description
Code
Description
0
No fault detected.
53
PDE in cylinder 3: The solenoid valve does not
work correctly.
11
Overspeed. One or both engine speed
sensors are displaying speeds in excess of
3000 r/min.
54
PDE in cylinder 4: The solenoid valve does not
work correctly.
12
Engine speed sensor 1 faulty, or incorrect
signal.
55
PDE in cylinder 5: The solenoid valve does not
work correctly.
13
Engine speed sensor 2 faulty, or incorrect
signal.
56
PDE in cylinder 6: The solenoid valve does not
work correctly.
14
Coolant temper ature sensor faulty, o r
incorrect signal.
57
PDE in cylinder 7: The solenoid valve does not
work correctly.
15
Charge air temperature sensor faulty, or
incorrect signal.
58
PDE in cylinder 8: The solenoid valve does not
work correctly.
16
Charge air pressure sensor faulty, or incorrect
signal.
59
Incorrect si gnal in extra analog inp ut.
17
Oil temperat ure sensor faulty, or incorrect
signal.
61
Incorrect control unit shutdown.
18
Oil pressure sensor faulty, or inco rrect signal.
66
Shutdown due to coolant level
21
Coolant level sensor faulty.
68
Alternator charging incorrectly.
23
Fault code internally i n the coordinator.
69
Starter motor fu n c tion interrupted or not
activated.
24
Accelerator/brake. If the accelerator and brake
have been operated simultaneously.
82
Engine speed above ref. speed at start
25
Accelerator sensor/idling switch
Accelerator sen s o r / k i c k-down switch
83
Fault in memory circuit (EEPROM ) in control
unit.
27
Engine shutdo wn bypassed.
84
Data transfer to the control unit memory
(EEPROM) has been interrup ted.
28
Shutdown due to oil pressure
85
Incorrect temperature internal ly in the control
unit.
31
Torque limitation due to oil pressure
86
Internal fault in the contr ol unit: Fault in
hardware control .
32
Incorrect parameter s for limp home functi on.
87
Fault in control unit RAM.
33
Battery voltage incorrect or no signal.
88
Internal control unit fault: Memory fault
37
Emergency shutd own switch activated in
accordance with CAN message from
coordinator.
89
Incorrect seal: Illegal editi ng of software.
43
CAN circuit faulty in the control unit.
93
Engine speed sensors faulty or not connected.
47
Immobiliser function. Ignition key code
incorrect.
94
Shutdown due to high coolant
temperature.
48
There is an inc orrect CAN message or no
CAN message from the coordinat or.
96
Torque limitation due to high
coolant temp erature.
49
Incorrect CA N version in control unit or
coordinator.
98
Incorrect v ol tage supply to one of the sensors.
51
PDE in cylinder 1: The solenoid valve does not
work correctly.
99
Internal hardware fault in the processor (TPU).
52
PDE in cylinder 2: The solenoid valve does not
work correctly.
